gl-spectrum

Spectrum rendering component with webgl or context2d.


Usage


``js
var Spectrum = require('gl-spectrum');

var spectrum = new Spectrum({
container: document.body,

//if undefined, new canvas will be created
canvas: null,

//existing webgl-context and some context options
context: null,
alpha: false,

//enable render on every frame, disable for manual rendering
autostart: true,

//visible range
maxDb: 0,
minDb: -100,
maxFrequency: 20000,
minFrequency: 20,
sampleRate: 44100,

//perceptual loudness weighting, 'a', 'b', 'c', 'd', 'itu' or 'z' (see a-weighting)
weighting: 'itu',

//display grid, can be an object with plot-grid settings
grid: true,

//place frequencies logarithmically
log: true,

//smooth series of data
smoothing: 0.75,

//0 - bottom, .5 - symmetrically, 1. - top
align: 0,

//peak highlight balance
balance: .5,

//display max value trail
trail: true,

//style of rendering: line, bar or fill
type: 'line',

//width of the bar, applicable only in bar mode
barWidth: 2,

//colormap for the levels of magnitude. Can be a single color for flat fill.
palette: ['black', 'white'],

//by default transparent, to draw waveform
background: null,

//pan and zoom to show detailed view
interactions: false
});

//pass values in decibels (-100...0 range)
spectrum.set(magnitudes);

//update style/options
spectrum.update(options);

//hook up every data set
spectrum.on('data', (magnitudes, trail) => {});

//for manual mode of rendering you may want to call this whenever you feel right
spectrum.render();
spectrum.draw();
``
